The QMP6990 is a digital barometric pressure sensor specifically designed for applications requiring high-precision pressure measurement, such as aircraft altitude control and portable navigation devices. It measures 2.0 × 2.0 × 0.95 mm3 in size.
This digital barometric pressure sensor is based on the piezoresistive sensing principle and offers long-term stability and EMC robustness. The QMP6990 can accurately detect absolute atmospheric pressure with a measurement range from 300 to 1250 hPa, which theoretically covers the main altitude range on the Earth’s surface. Under ideal steady-state conditions and with specific data output modes, the sensor can achieve an altitude resolution within 5 cm.
· Operation range：
Pressure：300 ~ 1250 hPa（Absolute）
Temperature：-40 ~ +85℃
· Built-in 24 - bit ADC：
Pressure resolution：0.015 Pa（1/64 Pa）
Temperature resolution：0.1℃
FIFO 576 bytes
Interrupt：Data ready，FIFO status
· Digital interface：
I2C：standard and fast modes
SPI：3-/4-wire， up to 10MHz clock
· Supply voltage：
VDD: +1.71V ~ +3.3V
VID: +1.71V ~ +3.3V
· Power consumption：
Standby ~ 1.2 uA
· RoHS-compliance package：
10-pin LGA with metal lid
2.0 × 2.0 ×0.95 mm3
